Mechanical Engineering

Laboratory Details
ENGINEERING PRACTICE LABORATORY

S.NoName of the major equipmentQuantity
1Arc welding transformer with cables and holders5 Nos.
2Welding booth with exhaust facility2 Nos.
3Welding accessories like welding shield, chipping hammer, wire brush, etc.5 Sets.
4Oxygen and acetylene gas cylinders, blow pipe and other welding outfits2 Nos.
5Universal bench type drilling machine2 Nos.
6Molding table, foundry tools2 Sets.
7Power Tool: Angle Grinder2 Nos.
8Assorted components for plumbing consisting of metallic pipes, plastic pipes, flexible pipes, couplings, unions, elbows, plugs and other fittings.15 Sets.
9Carpentry Vice (fitted to work bench)15 Nos.
10Standard wood working tools15 Sets.
11Power Tools:
(a) Circular Saw2 Nos.
(b) Jig saw2 Nos.
(c) Hand Drilling Machine2 Nos.
(d) Planer2 Nos.
MANUFACTURING TECHNOLOGY LABORATORY

S.NoName of the major equipmentQuantity
1Center Lathe11 Nos.
2Gear Hobbing Machine1 No.
3Centreless grinding machine1 No.
4CNC Milling Machine1 No.
5CNC Turning Machine1 No.
63D printing Machine2 Nos.
7Turret and capstan lathe1 No.
8Horizontal milling machine1 No.
9Vertical milling machine1 No.
10Surface grinding machine1 No.
11Radial drilling machine1 No.
12Tool maker microscope1 No.
13Shaping machine2 Nos.
14Tool and cutter grinder1 No.
15Lathe tool dynamometer1 No.
16Milling tool dynamometer1 No.
17Slotting machine1 No.
18Planer Machine1 No.
CAD/CAM LABORATORY
CAD Laboratory

CAM Laboratory


S.NoName of the major equipmentQuantity
1Computer Server1
2Computer nodes or systems (High end CPU with at least1GB main memory) networked to the server30
3Laser Printer1
4Any high end 3D modelling software30
5Licensed operating systemAdequate
6Computer work station15
7Color desk jet printer1
8Multi body dynamic software suitable for mechanism simulation and analysis15 lincenses
9C/Matlab5 lincenses

CNC Milling Machine

CNC Turning Machine

THERMAL ENGINEERING LABORATORY

S.NoName of the major equipmentQuantity
1I.C Engine stroke -2stroke and 4 stroke model1 set
2Pensky Marten Apparatus1 No.
3Redwood viscometer1 No.
44-stroke Diesel Engine with electrical loading (water rheostat )1 No.
54-stroke Diesel Engine with mechanical loading.1 No.
6Multi-cylinder Petrol Engine with hydraulic dynamometer1 No.
7Two stage reciprocating air compressor1 No.
8Refrigeration test rig1 No.
9Air-conditioning test rig1 No.
10Single cylinder diesel engine retardation test rig1 No.
11Four stroke Single cylinder petrol engine1 No.
12Four stroke twin cylinder diesel engine1 No.
13Blower test rig1 No.
MECHATRONICS LABORATORY

S.NoName of the major equipmentQuantity
1Hydraulics and Pneumatics Systems Simulation Software10 Nos
28051 - Microcontroller kit with stepper motor and drive circuit sets2 Nos
3Basic Pneumatic Trainer Kit with manual and electrical controls/ PLC Control each1 No
4Basic Hydraulic Teainer Kit1 No
5Image processing system with hardware & software1 No
KINEMATICS AND DYNAMICS LABORATORY

S.NoName of the major equipmentQuantity
1Cam follower setup1 No.
2Motorized gyroscope1 No.
3Governor apparatus - Watt, Porter, Proell and Hartnell governors1 No.
4Whirling of shaft apparatus1 No.
5Two rotor vibration setup1 No.
6Gear Models1 No.
7Kinematic Models to study various mechanisms1 No.
8Turn table apparatus1 No.
FLUID MACHINERY LABORATORY


Francis Turbine, Kaplan Turbine, Centrifugal Pump, Orifice Meter, Venturi Meter,Frictional losses in Pipes.

S.NoName of the major equipmentQuantity
1Orifice meter setup1 No.
2Venturi meter setup1 No.
3Rotameter setup1 No.
4Pipe Flow analysis setup1 No.
5Centrifugal pump/submergible pump setup1 No.
6Reciprocating pump setup1 No.
7Gear pump setup1 No.
8Pelton wheel setup1 No.
9Francis turbine setup1 No.
10Kaplan turbine setup1 No.
METROLOGY AND MEASUREMENTS LAB

Profile Projector, Vernier height Guage, Sinebar, Slip Guage set

S.NoName of the major equipment/InstrumentQuantity
1Micrometer1 No.
2Vernier Calliper1 No.
3Vernier Height Gauge1 No.
4Depth micrometer1 No.
5Slip Gauge Set1 No.
6Gear Tooth Vernier1 No.
7Sine Bar1 No.
8Floating Carriage Micrometer1 No.
9Profile Projector1 No.
10Tool makers microscope1 No.
11Force Measuring Setup1 No.
12Torque Measuring Setup1 No.
AUTOMATION AND METAL FORMING LABORATORY

S.NoName of the major equipment/InstrumentQuantity
1Universal tensile testing machine1 No.
2Hydraulic Press1 No.
3Water hammer setup1 No.
4Two high cold rolling mills1 No.
5Compressor1 No.
6FRL unit1 No.
7Single and Double acting cylinders1 No.
85/2 Pneumatic Direction Control Valve (DCV)1 No.
93/2 Pneumatic limit Switches1 No.
10Hydraulic Pump1 No.
11Hydraulic cylinder1 No.
124/2 or 4/3 Hydraulic DCV1 No.
13Pressure Relief Valve1 No.
145/2 Solenoid operated DCV1 No.
15Electrical limit switches or magnetic reed switches1 No.
164/2 Solenoid limit switches or magnetic reed switches1 No.
1724V DC Power Supply1 No.
18PLC with input and Output devices.1 No.
19Extrusion setup1 No.
20Automation Studio Simulation Software1 No.
INDUSTRIAL SAFETY AND ENVIRONMENTAL LABORATORY

S.NoName of the major equipment/InstrumentQuantity
1Noise level meter1 No.
2Friction tester1 No.
3Impact tester1 No.
4Exhaust gas analyzer1 No.
5High volume sampler1 No.
6PPE Set1 No.
7Fire extinguisher set1 No.
8Static charge tester1 No.
9First aid kit1 No.
10Lock out/Tag out1 No.
11Software: ALOHA, CAMEO1 No.
